The Stream ADU is a 540 SF 1 Bed 1 Bath Accessory Dwelling Unit (ADU) fitting a 32' 1" x 17' 3" footprint.
Stepping into the home you're immediately greeted by a cozy living room area with space for a mounted TV and multiple windows to allow light to flood in. As you venture further, you'll find a full-sized kitchen with ample storage space, followed by a stackable washer and dryer hidden in its own closet.
Across from the kitchen, is access to a full-sized bathroom with combination shower and tub. For maximum ventilation a 32" x 16" window is staged above the toilet. Finally, down the hallway, you'll encounter the spacious bedroom, with a massive walk in closet to the right, and a desk nook to the right, ideal for those looking to work from home or even to have a makeup station.
Within the design, everything is fairly streamlined, hence the name. You or your ADU inhabitants can easily flow from one end of the space to the other.
Delivery Options:
There are several options for the delivery of this plan set:
1) Plans Only - PDF & CAD FILE
We'll provide you the PDF & CAD files to customize the plans as needed for your submittal.
Included:
• PDF to Customize the Cover Sheet & Modifiable Pages
• CAD File of Floorplan, Elevations, & Cross-Sections to Send to Your Engineer
• Sheets Include:
Cover sheet, including fill -in-the-blank Project Data
Floor Plan
Elevations
Roof & Solar Plan
Cross-Sections
CA Green Building Code Forms
General MEP Details for Reference Only
General Notes Required for Plan Submittals in CA
Standard Imperial Dimensions
Not Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Structural engineering
• Full MEP Plans
• Processing Your Plan to Planning/Building Department Approval
2) Plans & Processing to Approval
For clients within 30 miles of DTLA, we'll create the full plan set for this ADU and get it approved in your city or jurisdiction. Once the plans are approved you'll receive 2 copies of the stamped, approved plans.
Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Processing Your Plan to Planning/Building Department Approval
• 2 Printed Copies of the 24” x 36” Plans Stamped by Your Local City or Jurisdiction (provided upon payment of permit fees)
• PDF of the Full Approved Plan to Share with Contractors
Not Included:
• Structural Engineering, Full MEP Plans
• CAD Files
To be eligible for this option the plans must be for a detached structure (ie. a 2-car garage or new construction) and the property must be located within 30 miles of Downtown Los Angeles, California.
If you're still in Southern California, but further than 30 miles from Downtown Los Angeles contact us directly for a quote.
