The Orchard ADU is a 360 SF 0 Bed 1 Bath Accessory Dwelling Unit (ADU) floorplan that is the floorplan inspired by the one we designed for a home on Orchard.

A distinctive aspect of The Orchard ADU’s design are the vaulted ceilings throughout the space. Stepping in from the front entry, you’re greeted with the powerful presence of a large open space coupled with an easy to use layout:

A spacious closet is added to the right of the bedroom space for storage. Next to it is a kitchen designed to fit a stackable washer and dryer, ample cabinets, dishwasher, and sink.

Finally, the bathroom with a standing shower and raised window further help to elevate the design.

Virtual Tour of the ADU

Delivery Options:
There are several options for the delivery of this plan set:

1) Plans Only - Hard Copies & CAD File

We'll print and ship 2 copies of the plans to you along with the CAD file.

Included:
• 2 Physical 24” x 36” Printed Copies of the Full Plan Set
• FREE Shipping with Tracking & Signature Confirmation USPS
• Bonus USB with Guide on How to Get the Plans Ready for City Submittal
• PDF to Customize the Cover Sheet & Modifiable Pages
• CAD File of Floorplan, Elevations, & Cross-Sections to Send to Your Engineer

Sheets Include:
Cover sheet, including fill -in-the-blank Project Data
Floor Plan
Elevations
Roof & Solar Plan
Cross-Sections
CA Green Building Code Forms
General MEP Details for Reference Only (including electrical plan)
General Notes Required for Plan Submittals in CA
Standard Imperial Dimensions

Not Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Structural Engineering, Full MEP Plans
• Processing Your Plan to Planning/Building Department Approval
• Full PDF of the Full Plan Review Set (PDF is just for the modifiable pages)

2) Plans Only - PDF & CAD FILE

We'll provide you a PDF & the CAD files to customize the plans as needed for your submittal.

Included:
• Full PDF of the Full Plan Set
• CAD File of the Floorplan, Elevations, & Cross-Sections to Send to Your Engineer, Designer, or Architect
• PDF Guide on How to Complete the Plans for City Submittal

Not Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Structural Engineering, Full MEP Plans
• Processing Your Plan to Planning/Building Department Approval

3) Plans & Processing to Approval

For clients within 30 miles of DTLA, we'll create the full plan set for this ADU and get it approved in your city or jurisdiction. Once the plans are approved you'll receive 2 copies of the stamped, approved plans.

Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Processing Your Plan to Planning/Building Department Approval
• 2 Printed Copies of the 24” x 36” Plans Stamped by Your Local City or Jurisdiction (provided upon payment of permit fees)
• PDF of the Full Approved Plan to Share with Contractors

Not Included:
• Structural Engineering, Full MEP Plans
• CAD Files

To be eligible for this option the plans must be for a detached structure (ie. a 2-car garage or new construction) and the property must be located within 30 miles of Downtown Los Angeles, California.

If you're still in Southern California, but further than 30 miles from Downtown Los Angeles contact us directly for a quote.
