"Lado" means side in Spanish, and acted as the inspiration for the name of this ADU. In construction, where you place rooms, particularly your bathroom and kitchen, can have a significant impact on your ultimate costs.
By pushing these areas all to one side, this design helps homeowners and investors potentially save money by making it easier for their contractors when it comes to running the plumbing and other undergound lines.
The Lado ADU is a 360 SF 1 Bed 1 Bath Accessory Dwelling Unit (ADU) ideal for a 18' x 20' garage conversion.
Characteristic of this layout is an open floor plan, helping to enlarge the space as a whole. The sleeping area large enough to fit a queen sized bed has a standard-sized closet to its right, and is located a short distance to the bathroom. While compact the kitchen packs all the essentials, with a design including space for a standard-sized fridge, oven, and 30" sink.
Lastly, inhabitants of The Lado ADU floorplan, can cozy up on a two-seater sofa in the living area with wall space for a large flat screen TV.
Take a virtual tour of the layout at your own pace using the link below.
Delivery Options:
There are several options for the delivery of this plan set:
1) Plans Only - Hard Copies & CAD File
We'll print and ship 2 copies of the plans to you along with the CAD file.
Included:
• 2 Physical 24” x 36” Printed Copies of the Full Plan Set
• FREE Shipping with Tracking & Signature Confirmation USPS
• Bonus USB with Guide on How to Get the Plans Ready for City Submittal
• PDF to Customize the Cover Sheet & Modifiable Pages
• CAD File of Floorplan, Elevations, & Cross-Sections to Send to Your Engineer
Sheets Include:
- Cover sheet, including fill -in-the-blank Project Data
- Floor Plan
- Elevations
- Roof & Solar Plan
- Cross-Sections
- CA Green Building Code Forms
- General MEP Details for Reference Only (including electrical plan)
- General Notes Required for Plan Submittals in CA
- Standard Imperial Dimensions
Not Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Structural Engineering, Full MEP Plans
• Processing Your Plan to Planning/Building Department Approval
• Full PDF of the Full Plan Review Set (PDF is just for the modifiable pages)
2) Plans Only - PDF & CAD FILE
We'll provide you a PDF & the CAD files to customize the plans as needed for your submittal.
Included:
• Full PDF of the Full Plan Set
• CAD File of the Floorplan, Elevations, & Cross-Sections to Send to Your Engineer, Designer, or Architect
• PDF Guide on How to Complete the Plans for City Submittal
Not Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Structural Engineering, Full MEP Plans
• Processing Your Plan to Planning/Building Department Approval
3) Plans & Processing to Approval
For clients within 30 miles of DTLA, we'll create the full plan set for this ADU and get it approved in your city or jurisdiction. Once the plans are approved you'll receive 2 copies of the stamped, approved plans.
Included:
• Submitting the Plans to Your Local City or Jurisdiction
• Processing Your Plan to Planning/Building Department Approval
• 2 Printed Copies of the 24” x 36” Plans Stamped by Your Local City or Jurisdiction (provided upon payment of permit fees)
• PDF of the Full Approved Plan to Share with Contractors
Not Included:
• Structural Engineering, Full MEP Plans
• CAD Files
To be eligible for this option the plans must be for a detached structure (ie. a 2-car garage or new construction) and the property must be located within 30 miles of Downtown Los Angeles, California.
If you're in Southern California, but further than 30 miles from Downtown Los Angeles contact us directly for a quote.
The Lado ADU - 360 SF 1 Bed 1 Bath
360 SF
